3D LED Flex Range

Modular + Linear + Flexible

The multi-award winning 3D LED Flex system has developed from a custom solution for a Zaha Hadid designed building into a comprehensive modular linear lighting system with a vast range of options.

Ideal for use in a wide range of interior, exterior and underwater lighting projects where curved lines of light are needed to illuminate non-linear building surfaces, columns and domes. The patented mechanical joint structure allows the individual modules to be bent and twisted in three dimensions to follow the most complex building contours.

  • Flexible in 3 Dimensions & hand-bendable and lockable on-site
  • Four sizes, for projects of all sizes. Up to 3,300 lumens per ft (11,000 lumens per mtr) from the 200 system down to 1,300 lumens per ft (4,000 lumens per mtr) from the 25 system.
  • IP ratings of IP20, IP44, IP65, IP66 and IP68 submersible
  • A wide range of LED light engine, reflector and lens options available. White light, RGB, RGBW, and dynamic white options available
  • Wide range of bracketry and anti-glare accessories to suit any application
  • Custom lengths up to 8.3’ (2.5 mtrs) based on a 4” (100mm) module length for the 25, 40 and 100 systems or an 8” (200mm) module length for the 200 system

Contact Radiant for any additional information.
